Snap-on has delivered its new Pro-Link+ diagnostic system, which provides diagnostic coverage for Class 1 to 8 trucks and code-specific repair guidance.
Pro-Link+ combines hardware and software to deliver a code-based diagnostic and repair platform for all-makes of trucks. It provides a direct path from pulling a fault code via the vehicle communication interface to diagnosing and fixing the problem.
It delivers:
- Code descriptions with step-by-step troubleshooting routines
- Testing procedures
- Component and connector photos
- Fault-specific wiring diagram
- Specifications and remove and install instructions
Validated by all major OEMs, the Pro-Link+ creates a reliable wireless or wired connection and supports the latest protocols including CAN FD and DoIP. When connected, the PRO-LINK+ identifies all fitted systems on the vehicle, displays active and inactive fault codes and automatically saves a vehicle health report.
The PRO-LINK+ hardware has been designed for commercial vehicle service environments. It has a 12-inch touchscreen, nine -hour battery life and integrated camera with light.
An internal microphone and stereo speakers are built in.
Additional and advanced features include
- OEM-level software for all makes of trucks, engines, transmissions and brakes is all-inclusive
- Live data graphing, component failure testing and replacement component programming
- The ability to adjust over 600 user-configurable parameters like cruise control, engine idle shutdown and service intervals
- Over 200 OEM special tests – including DPF regens, cylinder cutouts and fuel system leakage tests.
